Product Description
Product Details
In The Box
- (1) E-flite® Habu STS 70mm EDF
- (1) Brushless Outrunner Motor (installed)
- (1) 70A Brushless ESC (installed)
- (5) Sub-Micro Servos (installed)
- (1) Spektrum™ 3230B Flight Controller (installed)
- (1) Spektrum 4650C Serial Receiver (installed)
- (1) Spektrum DXS DSMX® 2.4GHz Transmitter
- (1) Product Manual
Needed to Complete
- (1) 3S 11.1V or 4S 14.8V 3200–4000mAh LiPo Battery with EC3™ or IC3® Connector*
- (1) Compatible LiPo Charger*
- *The recommended Spektrum™ Powerstage™ 3 bundle (SPMXPSA300) includes a compatible 3S 4000mAh Smart G2 LiPo battery and S120 USB-C Smart charger that can be used with a variety of USB power sources.
YOU CAN FLY A JET!
Nearly everyone who sees a radio controlled (RC) jet tear across the sky has the same reaction: "I want to fly one of those!" But because of their speed and handling challenges, RC jets have been almost impossible for first-time or low-time RC pilots to fly successfully — until now. Thanks to the E-flite® Habu STS (Smart Trainer with SAFE®) 70mm EDF jet, you can actually learn to fly RC airplanes successfully with a jet! The Habu STS 70mm EDF is based on the legendary Habu, one of the best high-performance Electric Ducted Fan (EDF) sport jet platforms ever created. E-flite® engineers optimized the design to improve its low-speed handling and slow speed performance and added options for taking advantage of exclusive Spektrum™ SAFE® flight assistance technology. As a result, the Habu STS 70mm EDF is the easiest to fly RC jet EVER, and the perfect choice to satisfy any RC pilot's desire to fly a jet!
Video Overview
Features
- Unique and optimized airframe design improves low speed handling and slow speed performance, making it possible to learn to fly radio-controlled (RC) airplanes successfully with a jet
- Based on one of the best first and high-performance EDF (Electric Ducted Fan) jet platforms ever designed — the legendary Habu
- Equipped with exclusive SAFE® technology that helps prevent crashes and makes it easy to learn how to fly
- Beginner, Intermediate and Experienced flight modes you can easily change between at the flip of a switch
- Panic Recovery mode at the push of a button to prevent loss of control and crashes
- Optional and easy to install Landing Assist Sensor (LAS) available for smoother landings
- Includes almost everything needed to fly except for a compatible LiPo battery and charger (sold separately)
- Use a 3S 3200-4000mAh battery for excellent performance overall, or a 4S battery for more power and speed
- Spektrum™ DXS controller/transmitter with industry-leading DSMX® 2.4GHz technology for reliable control without interference
- Spektrum flight controller and serial receiver with fly-by telemetry capability
- Powerful brushless electric power system with 70mm 10-blade fan
- 3S and 4S compatible 70-amp telemetry-capable ESC
- Five (5) factory-installed servos and linkages
- Oversized tires for operation from a variety of surfaces including grass
- Wide-stance tricycle landing gear with steerable nose wheel
- Quick and easy assembly — no glue or special tools required
- Lightweight yet strong and durable EPO construction
- Full line of replacement/spare parts available
- Practice flying this aircraft in the RealFlight® simulator (sold separately)
OPTIMIZED FOR EASY FLIGHT
Engineered for improved low speed handling and performance to make flying and landings easier, the E-flite® Habu STS (Smart Trainer with SAFE®) 70mm EDF makes it possible to succeed in learning to fly with a jet as your first ever radio controlled (RC) airplane! Based on one of the best Electric Ducted Fan (EDF) sport jets ever designed, it's been optimized with the addition of SAFE® (Sensor Assisted Flight Envelope) technology featuring Beginner, Intermediate and Experienced flight modes to make it easy to fly successfully, especially with the help of an instructor. Wide-stance tricycle landing gear with a steerable nose wheel and oversized tires allows for takeoffs and landings on surfaces ranging from paved runways to grass and even dirt, plus you can install the optional Landing Assist Sensor (LAS) that automatically "flares" for smoother landings to make learning to land even easier! Best of all, the durable EPO airframe assembles quickly and easily without the need for glue or special tools — which means you can be ready to fly in less time than it takes to charge a battery.
This Ready-To-Fly (RTF) Basic version includes everything needed to fly in one box except for a battery and charger. This allows you to choose a convenient and money-saving Spektrum™ Powerstage™ bundle or the separate battery and charger you prefer! The powerful brushless power system including a telemetry-capable ESC and the servos are all factory-installed. Plus the included Spektrum DXS 2.4GHz transmitter can be used with other Bind-N-Fly® (BNF) and BNF Basic aircraft after you learn to fly the Habu STS successfully!
And the fun doesn't stop after you learn how to fly! In the Experienced Mode, the Habu STS 70mm EDF is capable of performing aerobatic maneuvers including loops, rolls, inverted (upside down) flight and more. You can use a 3S 3200mAh to 4000mAh battery for an excellent balance of power and flight time, or you can install a compatible 4S battery for more speed and thrust without the need for any modifications or upgrades!
You can also purchase the RealFlight® Trainer Edition RC Flight Simulator and a Spektrum WS2000 Wireless Simulator Dongle (both sold separately) to fly this and other models using the transmitter included with the RTF Basic version! The simulator features six popular Horizon Hobby® trainer aircraft, including the Habu STS 70mm EDF jet, and built-in Virtual Flight Instructor lessons. This helps new pilots learn to fly successfully by practicing on a PC at home or on a laptop just about anywhere else!
Video Overview
Flight Talk
BONUS Flight Talk: 4S
Ready-To-Fly Basic Flexibility
This Ready-To-Fly (RTF) Basic version includes a Spektrum™ DXS controller/transmitter equipped with industry-leading DSMX® 2.4GHz technology and everything else you need to fly except for a rechargeable lithium polymer battery and charger for the airplane. The convenient and money-saving Spektrum™ Powerstage 3 bundle (SPMXPSA300) includes a compatible 3S 4000mAh Smart G2 LiPo battery and an S120 USB-C Smart charger that can be used with a variety of USB power sources. Or you can choose the separate 3S or 4S 3200–4000mAh battery and compatible charger you prefer!
Uniquely Optimized
Jets are typically faster and harder to fly than most of their prop-driven counterparts, which made it impossible for first-time, and even low-time, RC pilots to fly them – until now! The unique and optimized airframe design of the Habu STS improves low speed handling and slow speed performance to finally make it possible to learn to fly radio controlled (RC) airplanes successfully with a jet.
High Power
The factory-installed brushless power system features a 70-amp telemetry-capable ESC plus a specially-tuned motor and 10-blade 70mm fan that delivers an abundance of thrust with a 3S LiPo battery, or more power and speed with a 4S battery without the need for any modifications or upgrades.
Durable Design
Construction with advanced EPO material delivers a lightweight yet durable airframe that's tough enough to handle everyday flying punishment without getting bent out of shape. And in the unfortunate event you damage any airframe parts or components and can't repair them, a full line of replacement parts is readily available.
Easy Assembly
The Habu STS 70mm EDF arrives mostly factory-assembled with the power system, servos plus the flight controller and receiver installed. All you need to do is finish some quick and easy final assembly, without the use of glue or special tools, and you'll be ready to fly in less time than it takes to charge a battery!
Capable Gear
The wide-stance tricycle landing gear with a steerable nose wheel and oversized tires offers improved ground handling for easier take offs and landings on a wide variety of surfaces from paved runways to grass and even dirt.
Flight School Qualifying Trainer
This trainer model qualifies for use in the Horizon Hobby Flight School. As a trainer, this plane needs minimal preparation to be flight-ready. It also includes SAFE® (Sensor Assisted Flight Envelope) technology to help new pilots control their models. Purchase this item along with a three-month AMA trial membership to get started. More information can be found here!
If this is your first RC airplane, Horizon Hobby-exclusive SAFE (Sensor Assisted Flight Envelope) technology prevents over-control and crashing while also offering multiple flight modes to deliver more control and capabilities as your skills progress:
Beginner Mode
Pitch and bank angle limits prevent over-control that can result in a loss of orientation and crashes. When the control sticks are released the airplane returns to level flight on its own. Best of all takeoffs are as simple as giving full throttle and letting the airplane fly off the ground or by giving it a quick hand launch.
Intermediate Mode
More freedom in pitch and bank, but still prevents over-control and does not return to level flight on its own. This mode allows you to make tighter turns and to climb and descend faster as your skills advance. Beginner mode automatically activates and returns the airplane to level flight when the airplane descends below approximately 30 feet above ground level and the sticks are released.
Experienced Mode
No pitch or bank angle limits so you have complete control! You can even fly inverted (upside down) and perform aerobatic maneuvers including loops, rolls, stall turns and more. Panic Recovery Mode can be activated by switching to Beginner Mode and releasing the sticks.
Panic Recovery
If you ever lose control of the airplane in the more advanced control modes simply switch to Beginner Mode and release the control sticks. SAFE® technology will automatically return the airplane to level flight.
Product Specifications
| Radio | Included |
| Technology | Smart, AS3X and SAFE |
| Charger | Sold Separately |
| Receiver | Included |
| Product Weight | 46.4oz (1316g) without Battery |
