Product Description
This is a RC4WD Gelande II BFGoodrich 150th Anniversary RTR 1/10 Scale 4WD Crawler is a versatile model that can pull off multiple looks and styles. The limited edition red, blue and white color scheme commemorates BFGoodrich's 150th year anniversary along with custom factory-applied decals. The Cruiser Body has an awesome assortment of scale details including mirrors, door handles, vents and a grill to match the 1:1 real vehicle. All lights and marker lamps can be illuminated with an optional RC4WD LED light kit.
The G2 is built with quality materials and craftsmanship, with features like the R3 single speed transmission to provide power down to the transfer case and out to the proven Yota II axles. A four link rear and three link panhard bar suspension as a standard feature and the chassis mounted servo is out of view for a more scale appearance. From emergency and expedition vehicles to daily drivers and hard core rock climbing rigs, the core of the G2 is built for the true off-road enthusiast.
Features:
- Custom Designed for True to Scale Looks
- Realistic Aluminum Ladder Frame Chassis
- R3 Single Speed Transmission
- Center Mounted Realistic 4X4 Transfer Case
- Yota II Ultimate Scale Cast Axles
- 3 Link Front and 4 Link Rear Suspension
- RC4WD Chrome 1.9" Beadlock Wheels
- RC4WD BFGoodrich Mud Terrain T/A KM3 1.9 Tires
- Chassis Mounted Steering Servo
- Plastic Fuel Cell Receiver Box
- Dual Spring Oil Filled Shock Absorbers
Specifications:
Hammer Transfer Case
Ratio: 1.47:1
Gears: Wide .8 Mod Hardened Steel Gears, 8 Bearings, Cast Casing
R3 Single Speed Transmission
Ratios: Pinion/Spur 14/64 = 4.57:1
Internal Ratios: 1.78:1
Gears: - Wide Steel .8 Mod, Delrin Spur, Slipper Clutch
Yota II Ultimate Scale Cast Axles
Ratio: 15/40 = 2.67:1
Width at Hex (Using 4mm TF2 Hexes): 178.2mm
G2 Suspension: 3 Link Suspension with Panhard Bar, Double Triangulated 4 Link Rear Suspension
Shock Absorbers: Dual Spring 80mm Shocks - Can be Oil Filled
Wheels:
Type: RC4WD Chrome 1.9" Beadlock Wheels
Hub: 12mm Hex
Width: 26mm (1.02")
OD: 54mm (2.14")
Bumpers: Machined Billet Aluminum, Lightweight
G2 Truck Dimensions
Wheelbase: 10.8in / 275mm
Length: 18.3in / 465mm
Width: 8.2in / 210mm
Height: 10.7in / 274mm
Ground Clearance: 2.4in / 61mm
Final Drive Ratio: 31.9:1
Weight: 8.35Lbs / 3.79Kg
Includes:
- (1) RC4WD Gelande II RTR 1/10 Scale Truck Kit
- (1) Cruiser Body Set (BFGoodrich 150th Anniversary Edition)
- (1) 2.4GHz Radio
- (1) Decal Sheet
- (1) 6S 3000mAh NIHM battery
- (4) AA Batteries
- (1) Lipo Charger
Needed to Complete:
- Everything is in the box!
