Product Description
DESCRIPTION
The MINI-Z RWD MR-03 series replaces the MR-03 Sports 2 and is positioned slightly above the predecessor. Combined with the new KT-531P transmitter and full ball bearing specifications, the MINI-Z RWD provides users with more values at the same price range. The KT-531P transmitter features soft foam steering wheel, which will give you a higher driving pleasure, and the transmitter is equipped with the throttle trim control knob, which was omitted from the KT-19. The new RX unit is equipped with the expansion ports for optional gyro units (MZW431) and light unit (MZW429R). The gyro effect can be adjusted by turning the small volume on the RX board, and the head light flashing speed can be remote controlled from the transmitter.
READY SET CONTENTS
Factory-assemlbed chassis equipped with KT-531P compatible Rx-ESC unit
Painted and marked plastic body shell
Tread width conversion parts
Pinion Gears (6T, 7T, 8T, 9T)
Front suspension adjustment spacers
Pinion gear removal tool
Spare wheel nuts
Wheel wrench
Wheels and tires
REQUIRED FOR OPERATION
8 x AAA batteries
TECHNICAL DATA
Length: 172.5mm
Width: 75.0mm
Height: 49.0mm
Chassis Type: MR-03W-MM
Wheelbase: 98.0mm
Tread (F): 64.5mm
Tread (R): 62.0mm
Weight: 130g
130 class motor
Gear Ratio: 7.3, 6.3, 5.5, 4.9:1
Tire Diameter (F/R): 25.0mm/25.0mm
Tire Width (F): 8.5mm
Tire Width (R): 11.0mm
Transmitter: included (KT-531P)
Tpo Speed: approx. 17km/h
Runtime: approx. 50min.
Features:
- KT-531P transmitter features steering trim, throttle trim, steering D/R, light flashing speed
- Soft foam steering wheel ensures delicate non-slip steering control
- Full ball bearing specifications
- MR-03 Compatible chassis components
- Almost all optional parts MR-03 and MR-03 Sports can be used
- Gyro socket and adjustment volume equipped
