Product Description
Experience the thrill of dirt late model racing with the 22S Dirt Late Model. The 22S DLM features proven TLR 22 race geometry, a low center of gravity for confident cornering, and a race-ready brushless power system. The clipless body design makes maintenance effortless, while compatibility with Losi and TLR option parts means nearly endless upgrade possibilities. Dominate the oval like never before.
Product Details
In The Box
Needed to Complete
Losi 1/10 22S 2WD Dirt Oval Late Model RTR, Blue Overview
With the 1/10 scale, ready-to-run 22S Dirt Late Model, Losi expands its dominance in RC dirt oval racing by delivering the most authentic late model experience available right out of the box.
Dirt late model racing is one of the most exciting forms of American motorsports. The closed-wheel design enables aggressive side-by-side racing, allowing passing moves that sprint cars can't match. With a lower center of gravity and no wings to manage, late models deliver a driving experience that's both faster-feeling and more forgiving on tracks.
RC dirt oval racing has exploded in popularity across the United States. Losi 22S Dirt Late Model adds to the excitement. The 22S Dirt Late Model delivers championship-level performance and accurate scale realism at a fraction of the cost of a custom build, with the convenience of ready-to-run ease. Based on the competition-proven Team Losi Racing TLR 22 geometry that also powers the 22S Sprint, it shares the same race-engineered suspension and drivetrain components that experienced racers demand.
An aluminum chassis, steel turnbuckles, and all-metal transmission provide the durability to survive wheel-to-wheel battles on dirt oval tracks. The sealed gear differential comes pre-filled with diff fluid for optimal performance. A customizable battery tray expands your options with adjustable stops for full-length or shorty packs. The installed Spektrum 2S brushless system powers the 22S DLM around the oval, hitting 25+ mph down the straightaways.
Authentic scale details bring late model realism to life. It features an accurately designed body with the correct skew and twist found on full-scale late models for maximum downforce, a hand-painted driver figure and race seat, scale details including a realistic dash panel, steering wheel, air cleaner, fuel door, and much more. The officially licensed Hoosier tires in a soft compound are ideal for most tracks, with medium compound versions available separately for high-traction, high-wear surfaces.
The 22S Dirt Late Model excels on purpose-built RC Dirt oval tracks that are either dirt or clay, banked or flat, small or large. But it's equally thrilling on simple ovals marked with cones in driveways, parking lots, or even basketball courts. Its versatility makes dirt oval racing accessible anywhere.
Performing maintenance, or even replacing the battery pack, on RC vehicles with detailed bodies and roll cages can be challenging. The 22S DLM solves this with an innovative clipless mounting system. Press the button on the molded air cleaner, then pull up and slide forward, and the entire body and cage assembly lifts off the chassis. Maintenance, repairs, and upgrades have never been easier.
For racers looking to gain a competitive edge, the 22S Dirt Late Model accepts existing Losi and TLR option parts. Since it shares suspension and transmission components with the 22S Sprint, many hobby shops will support both racing classes with shared parts inventory. Body panel templates are available for download to create custom vinyl wrap liveries.
Get ready to experience the aggressive racing that makes dirt late models legendary. With the Losi 22S Dirt Late Model, you can own the oval!
- Fully assembled and ready to run - only battery and charger required
- Race-ready Spektrum 2S brushless power system
- Clipless body mounting for easy chassis access
- Based on competition-proven TLR 22 geometry
- Low center of gravity for confident cornering
Losi 1/10 22S 2WD Dirt Oval Late Model RTR, Blue Features
- Officially licensed Summit Racing livery
- Hand-painted driver figure with race seat
- Steering wheel and Detailed Dash Panel
- Authentic body with correct skew and twist for maximum downforce
- Scale-correct wide 5 wheels with integrated hub design
- Officially licensed Hoosier tires
- Clipless body mounting for easy chassis access
- Templates for body panels available to download
- Decal Sheets with Custom Numbers & Letters
- 2.5mm 6061-T6 aluminum chassis
- Threaded aluminum shock bodies
- Adjustable steel turnbuckles
- All-metal gear transmission
- Adjustable dual slipper clutch
- Sealed gear differential, pre-filled with 3000cSt diff fluid
- Adjustable battery tray with easy-to-use elastomer straps
- Accepts many existing Losi and TLR option parts
- Based on competition-proven TLR 22 geometry
- Race-ready brushless power system
- Ready to run - includes battery and charger
- Powerful Spektrum brushless power system
- Spektrum SLT2 2.4GHz transmitter
- Spektrum SR215 DSMR 2-channel receiver with Transponder port
- Spektrum S684 25T waterproof metal gear steering servo
- Spektrum Smart 2S G2 4000mAh 30C LiPo with IC5 connector
- Spektrum Smart S160 USB-C 1x60W Charger (IC5)
- AA Transmitter Batteries (4)
- Metal 4-Way Nut Driver
- Composite Shock Tools
READY TO RUN
The Losi 22S Dirt Late Model is fully assembled and ready to run. Just install your choice of the recommended Spektrum batteries and you're all set for dirt oval action.
ALL-METAL TRANSMISSION
The Losi 22S Dirt Late Model's all-metal transmission features an adjustable dual-slipper clutch and a sealed gear differential, pre-filled with diff fluid for optimal performance.
DURABLE CONSTRUCTION
Race-proven features, including an aluminum chassis, aluminum-bodied shocks, and adjustable steel turnbuckles, an all-metal-gear drivetrain, and durable composite blend injection molded parts, combine to give the Losi 22S Dirt Late Model the durability to withstand intense wheel-to-wheel competition week after week.
CUSTOMIZABLE BATTERY TRAY
The 22S Dirt Late Model expands your battery options with a customizable battery tray featuring adjustable stops for full-length or shorty batteries. Easy-to-use elastomer straps hold your battery securely in place.
LOSI AND TLR-TUNED OPTION PARTS AVAILABLE
Drivers can keep their 22S Dirt Late Model in peak form and gain a competitive edge with an extensive selection of Losi and TLR-Tuned option parts. Built on the race-proven TLR 22 platform that has dominated 1/10 scale electric racing, the 22S Dirt Late Model shares suspension and transmission components with the 22S Sprint, making most 22S Sprint option parts compatible. This compatibility, combined with the wide range of already-available TLR-Tuned performance upgrades, gives racers countless ways to fine-tune and optimize their Dirt Late Model for maximum performance.
LOADED WITH SCALE DETAILS
Authentic details enhance the 22S Dirt Late Model's realistic appearance. The body is designed with the correct skew and twist as found on full-scale late models to maximize downforce and an authentic appearance. Other details include a hand-painted driver figure with a race seat, steering wheel, and a detailed roll cage that matches real late-model designs.
DESIGN YOUR OWN LIVERIES
Design your own liveries to customize the look of your Losi 22S Dirt Late Model. The body panel templates are available as a free download. With these, you can create new liveries of your own.
POWERFUL BRUSHLESS POWER SYSTEM
The 22S Dirt Late Model is equipped with a Spektrum 2S brushless system. It features the Firma 45A Smart Lite ESC and the Firma 3650 3300Kv brushless motor-a combination that delivers the power to reach speeds of 25+ mph.
SPEKTRUM SLT2 TRANSMITTER
In addition to providing interference-free control, the included Spektrum SLT2 2.4GHz transmitter offers steering trim, steering rate, steering reversing, and other useful features. Novice drivers can use the throttle limiting switch to set the top speed to 50% or 75% of the vehicle's full potential, ideal for gradually and safely developing control skills.
SPEKTRUM S684 SERVO
The 22S Dirt Late Model includes a Spektrum S684 high-speed metal-gear servo with a 25T adjustable servo saver for durable, powerful steering. Its waterproof design lets you race with confidence in any conditions. We also include an optional solid servo horn for expert drivers who want the most precision from their DLM.
SPEKTRUM SR215 DSMR 2-CHANNEL SPORT RECEIVER
The factory-installed, telemetry-equipped Spektrum SR215 is a dual-protocol DSMR receiver that also connects to advanced racing radios such as the DX5 and iXSR. Its lightning-fast 5.5ms frame rate delivers a quick, low-latency connection for pro-level enthusiasts. The streamlined case offers added antenna support and an integrated antenna tube slot for easy installation. The battery port can also power a lap-counting transponder.
CLIPLESS BODY MOUNTING
RC vehicles with detailed bodies and roll cages often are difficult to work on - sometimes the cage must be removed to access the chassis for repairs, maintenance, or upgrades. On the Losi 22S Dirt Late Model, you simply press the button on the molded air cleaner, pull up and slide forward, and the entire body and cage assembly lifts right off the chassis. It makes chassis access fast and easy!
Losi 1/10 22S 2WD Dirt Oval Late Model RTR, Blue Product Specs
- Approximate Assembly TimeLess than 1 Hour
- BatterySold Separately
- ChargerSold Separately
- ChassisAluminum
- Completion LevelReady-To-Run
- Connector TypeIC5
- DifferentialDiff Oil: 3,000cSt
- Drive TypeForward/Brake/Reverse
- Drivetrain2WD
- Final Drive Ratio10.21:1
- Internal Gear Ratio2.43:1
- LiPo Compatibility2S
- Motor Size3650 3300Kv
- Motor TypeBrushless
- Pinion20T
- Power System2S
- Power TypeElectric
- Product Height6.4" (163 mm)
- Product Length24.25" (616 mm)
- Product WeightWithout Battery: 5.49 lb (2.5kg)
- Product Width11.8" (300 mm)
- RadioIncluded
- ReceiverIncluded
- Scale1/10
- ServosIncluded
- Shock TypeShock Oil: Front: 30wt Rear: 35wt
- Spur GearIncluded: 84T
- Top Speed25+
- Vehicle TypeOval
- Wheel Hex Size12mm
