Product Description
Key Features
- Digital precision and power
- Low deadband accuracy
- Dual ball bearing support
- Plastic Gears
- Coreless Motor
Overview
The A5030's lightweight plastic gear train, digital precision and incredible .10 transit time is ideal for 25-32 size aircraft. Aerobatic and 3D aircraft that demand performance need the precision of digital accuracy. This servo is ideal and will last the pilot a long time thanks to its tight nylon gear train.
This mini-class servo is durable enough for either glow or electric power applications. Dual ball-bearing support means there’s less resistance to the high output of the high-speed coreless motor. In all these features mean you can expect great performance and long life.
Specs
| Bearing | Dual |
| Bushing Or Bearing | Bearing |
| Gear Material | Nylon |
| Maximum Servo Speed | 0.100-0.149 sec |
| Maximum Servo Torque | 40-99 oz-in |
| Motor Type | Coreless |
| Product Height | 1.10" (28.0mm) |
| Product Length | 1.30" (33.0mm) |
| Product Weight | 0.83 oz (23.6 g) |
| Product Width | 0.58" (15mm) |
| Programmable | No |
| Servo Operating Voltage | 4.8 - 6.0V |
| Servo Size Category | Mini and Micro |
| Servo Type | Digital |
| Speed | 0.12 sec/60 deg @ 4.8V; 0.10 sec/60 deg @ 6.0V |
| Torque | 50 oz-in (3.6 kg-cm) @ 4.8V; 66 oz-in (4.8 kg-cm) @ 6.0V |
