Description
Key Features
- High torque both on HV and non-HV applications
- Allows BECs of adjustable BEC ESCs to be set higher to increase performance
- Acts as a heat sink for the motor and ESC
- Low deadband, high resolution, with impressive holding torque for unmatched performance
- Durable high performance finish
Overview
Spektrum high-voltage, brushless servos deliver dependable power and digital precision with amazing efficiency. Finely tuned electronics and software integrate with powerful brushless motor technology to offer ultra-smooth, high-speed performance more efficiently than servos with conventional motors. The all-aluminum case provides the ultimate solution in durability and heat dissipation, while precision metal gears complete a satisfaction package even the most critical pilot can appreciate.
The Spektrum A5070 mini servo uses this solid foundation to achieve a whopping 190 oz/in of torque* and high transit speeds of .07 sec* in addition to its outstanding balance of durability, value, plus the peace-of-mind that sophisticated error correction and over-current/temperature protection offers. It’s an impressive feature combination that makes this mighty servo an outstanding airplane or heli servo choice.
Product Specifications
Specs
| Application | Airplane or Heli |
| Bearing | Dual |
| Bushing Or Bearing | Bearing |
| Connector Type | Universal |
| Connector Wire Length | 11.8 in (300mm) |
| Deadband | 2?s |
| Gear Material | Metal |
| Gear Type | Metal |
| Maximum Servo Speed | 0.050-0.099 sec |
| Maximum Servo Torque | 100-199 oz-in |
| Motor Type | Brushless |
| Overload Protection | Yes |
| Product Height | 1.16 in (29.4mm) |
| Product Length | 1.32 in (33.5mm) |
| Product Weight | 1.4 oz (40g) |
| Product Width | 0.59 in (14.9mm) |
| Programmable | No |
| Rotation Range | 120? |
| Servo Operating Voltage | 6.0 - 8.4V (HV) |
| Servo Size Category | Mini and Micro |
| Servo Type | Digital |
| Speed | 0.094 sec/60 deg @6.0V; 0.078 sec/60 deg @ 8.4V |
| Spline Count | 23 Teeth |
| Torque | 146.43 oz-in @6.0V; 190.58 oz-in @ 8.4V |
| Wire Gauge | 22 AWG |
Additional Details
- SKU:
- 400000010953
